smd outdoor led displays



Under the development of advanced LED technology, SMD indoor LED screen is becoming to apply to outdoor and sharing marketing with DIP LED lamps. It is well known that outdoor LED billboards were all use DIP devices few years ago. However, due to the low brightness of SMD modules and unable to adapt to the outdoor complex environment, thus SMD LED display board can only be used to indoor applications. And now, SMD panel got increasingly technological development in LED outdoor application market.



Obvious advantages of outdoor SMD screen:
Compare to LED DIP display products, SMD display screen posses the advantages of wide viewing angle, good lighting distribution, high contrast ratio. Outdoor SMD LED display not only has wide viewing angle of 110 degrees in the horizontal direction but also has more than 110 degree wide viewing angle in the vertical direction. Therefore, high building outdoor advertisement LED display should need a outdoor SMD full color screen with wide viewing angle to show better advertise effect.



p6.6-front-service-smd-outdoor-led-display-modules



In addition, outdoor SMD panel has better consistency while DIP LED lamps (green, red, blue) are hard to achieve consistency index. But smd outdoor panel could make these 3 color brightness have a highly consistency. SMD LED board make sure the outdoor full-color smd LED display brightness consistency at any angle to achieve better color fidelity effect.


Moreover, the volume of SMD full-color screen is smaller than DIP, so the luminous area is small and larger black area, which improve the contrast of LED display screen. SMD is packaged in a designed structure, its built-in red, green blue 3 chips that could be as one pixel for the whole screen. However, DIP LED lights only have one color chip built-in, so it needs three different color lamps to put together to be as a pixel, Therefore, the mixing effects of SMD full color display are better than upright oval LED display.



Whatsmore, Outdoor full-color smd LED display is free to pot glue and the products are more thin, easy and quick installation. Using aluminum alloy cabinet structure design, beautiful shape, easy to assemble. Suitable for LED rental companies, taxi-top screen, mobile media, etc.



Outdoor smd panel circuit design can be designed light and drive 2 in 1, easy automated production. Outdoor smd not only improves the reliability also has promoted the production efficiency. More importantly, decrease the cost. According to the above theory, VERYPIXEL summarized as follows: Outdoor smd display has two significant advantages compared to LED DIP screen: firstly, Outdoor smd displays effect and viewing effect is better; secondly, Large viewing angle make outdoor smd more suitable for smaller spacing LED display than DIP LED display.



Due to marketing demand, small space full color LED display screen is needed more but traditional dip modules is obviously unable to meet the needs of the application marketing.



With the maturity development of LED packaging technology, LED lamp & SMT chip widely used in this field. Comparing with the traditional upright oval LED full color display, Outdoor smd displays have better display effect, more energy-saving, thin cabinet, larger viewing angle, no matter apply to indoor or outdoor. VERYPIXEL think that SMD led displays will take the place of DIP oval full-color LED billboards in the near future.



Verypixel SMD Outdoor LED Displays
